CONTROL DISPLAY
SHIMANO STEPS logo screen
This screen is displayed during system start
up and shutdown.
Basic screen display
Displays the status of the power assisted
bicycle, traveling data.
The number of gears and the shifting mode
are only displayed when using electronic
gear shifting.
1. Current speed
Displays the current speed.
2. Battery level indicator
Displays the current battery level.
3. Speed unit display
You can switch between km/h and mph.
4. Changing the assist mode display
Display the current assist mode.
5. Gear position and traveling data display
Displays the current gear position or
traveling data. Operate the assist switch to
change the display for SC-E6000 from the
gear position display to the traveling data
display.
6. Current time
Shows the current time.
7. Gear shifting mode
The current gear shifting mode is displayed
as following:
SC-E6000: [A] (Auto)/[M] (Manual)
SC-E6010: [Auto]/[Manual]
38 - EN
