Rundo bath shower set
List of the standard accessories
Please double-check the accessory list hereinafter and contact our company or our distributor for
any unconformity.
Remarks:
– Without affecting their performancing, accessories may
be changed without further notice;
– Drawings for reference only, Product size & shape refer
to actual faucet!
Installation Instructions
1. Do not disassemble the main body, as it has been installed & commissioned correctly &
precisely before leaving the factory!
2. To avoid the faucet from jamming, do flush the water pipe before installation!
3. After installation, make sure every joint safely sealed & no
leaking!
4. Using condition: Working pressure at 0.05-1.0 MPa
(including cold & hot water pressure), with applicable water
temperature: 4 °C-90 °C.
5. Make sure to connect the hot/cold inlet pipe correctly, if
standing in front, hot water pipe connecting to the left & cold
water pipe connecting to the right!
Aerator
Code
The Accessory List
1
Handwheel
2
Screw
3
Index
4
Adapter
5
Base
6
O-ring
7
Gasket
8
Lock nut
9
Screw
10
Headwork
11
Spout
12
Main body
13
Hand shower
14
Shower hose
15
Shower base
16
O-ring
17
Base
18
Weight
19
Connect hose
20
Flexible connections
Do not
disassemble!
|
EN
|
Quantity
3
3
3
3
3
4
5
5
15
2
1
1
1
1
1
1
1
1
3
2
Flush
the pipe!
