| FUNCTIONS AND DISPLAY

DISPLAY OVERVIEW

Load
10Ω 470Ω
22Ω 1kΩ
47Ω 22kΩ
100Ω 47kΩ
220Ω
EQ Curves
Vinyl records were pressed by different labels: each and every one could develop and use a different
way to record and print records thus creating different equalisation curves.
Aligning the curves of equalisation of reproduction to match the curves used to produce the record is
the best way to extract the correct audio signal from the vinyl.
PH-5 offers a variety of the most commonly used curves, starting with the standard RIAA, followed by
the acclaimed original DECCA LONDON and the AMERICAN COLUMBIA.
Every curve is also offered in its ENHANCED version that can result in a crisper, more vivid sound
extracted from the vinyl and sometimes useful to achieve even greater dynamic.
Type selection
MM
MC
RIAA
DISP
Adjusts the brightness.
If set to OFF, the display is temporarily activated
for a few seconds when using the unit.
5
Gain
-6 dB
0 dB
+3 dB
+6 dB
