Digital BBQ meat thermometer
5. Elements
A: Display (Fig. 2):
A 1: Actual temperature
A 2: Target temperature
A 3: Battery symbol
B: Sensor buttons (Fig. 1+2):
B 1: ON/OFF button
B 2: + button
B 3: – button
C: Housing (Fig. 3):
C 1: Battery compartment
C 2: Stand (fold out)
C 3: Magnet
D: Probe (Fig. 1):
D 1: Probe
D 2: Cable
D 3: Probe connector
14
16:03 Uhr Seite 8
6. Getting started
• Remove the protective film from the display.
• Pull the rubber protection from the stainless steel probe.
• Plug the connector for the sensor cable into the socket.
• Open the battery compartment and insert two new AAA
1,5 V batteries. Make sure the polarity is correct. All seg-
ments will be displayed briefly.
• Close the battery compartment again.
• The current temperature and the target temperature
(77°C default) appear on the display.
• The device is ready for use.
7. Operation
• Press the ON/OFF button to switch on the device.
• If no button is pressed within 10 seconds, the backlight
switches off automatically.
• Press the ON/OFF button briefly to activate the backlight
again.
• Each button operation is acknowledged with a beep.
• Press and hold the + or – button for fast mode.
Digital BBQ meat thermometer
• Press ON/OFF button for 2 seconds to deactivate the
device.

7.1 Measuring procedure

• Plunge the probe at least 2.5 cm into the middle of the
thickest part of the meat, for poultry between the torso
and the thigh; it should not touch bones or cartilage and
it should not protrude from the meat. Put the meat into
the oven and set the relevant oven temperature.
• Simply run the cable to the outside. The cable adapts to
the oven seal. Be careful with sharp-edged frames and
hinges.
• Use the magnet to fasten the thermometer in position
near the oven (cable length 100 cm) or fold out the stand
and place the device onto a flat surface.
• Press the + or – button to set the desired internal tem-
perature.
• When the target temperature is reached, an alarm tone
will sound.
• The backlight turns on.
• Remove the probe and turn off the instrument to stop the
alarm.
• The alarm tone continues sounding until the temperature
drops below the selected alarm value.
8. Care and maintenance
• Clean the instrument and the probe with a soft damp
cloth. Do not use solvents or scouring agents. Protect it
from moisture.
• Should water or steam enter the device's jack, it could
affect the contact with the probe. Dry the probe connec-
tor with a cloth before you connect it to your instrument.
• Turn off the instrument after use.
• Remove the batteries if the device will not be used for an
extended period of time.
• Keep the device in a dry place.

8.1 Battery replacement

• Change the batteries when the battery symbol appears
on the display.
