description of the monitor

Connectors
1
1 Power connector
2 HDMI 2.0 port
3 VGA port
4 Audio IN port
5 3.5 mm headphone jack
6 Security slot: Attaches to 3x7 mm cables (not included and sold separately).
16
2 3 4 5

Control button

5-way control button
6
Short press
Long press (3 seconds)
Press upwards
Press downwards
Press to the right
Press to the left
Note:
• The control button does not disconnect the appliance from the electrical supply. If you want to
disconnect the monitor from the electrical supply, disconnect the adapter unit.
Standard use Navigating the menus
Turning on the screen Confirm
Turn off the screen
Automatic settings (only in Navigate upwards
VGA mode)
Access the configuration Navigate downwards
menus
Access volume settings Access next sub-menu /
Increase a value
Access brightness settings Access previous sub-menu /
Decrease a value
