Temperature
•
Colour
Blue light filter
•
Language
•
Horizontal or
•
vertical position
Standby mode
•
Interface
Transparency
•
Auto settings
•
AutoColor
•
Reset
•
Reset
Inputs
•
Mute
•
Volume
•
FreeSync
•
Extra
20
Cold: Opt for cool colour display (predominance of
•
blue).
Normal: Opt for midway colour settings.
•
Warm: Opt for warm colour display (predominance
•
of red)
User: enables personalised colours (red/green/
•
blue) displayed on screen.
Adjust the blue light filter level.
•
Select the menu language.
•
Manually adjust the vertical (V) and horizontal (H)
•
position of the menu on screen.
Select menu display time.
•
Adjust menu transparency level.
•
Automatic image adjustment.
•
Automatic colour adjustment.
•
Pivot the multifunction button to the right to reset
•
settings.
Select source: VGA or HDMI.
•
Activate or deactivate speaker volume.
•
Adjust speaker volume.
•
Enable or disable the FreeSync function.
•

troubleshooting guide

Before contacting the service department, please carry out the checks listed below. If you cannot
solve the problem by following the instructions below, contact your local retailer or a qualified
technician.
1. Check that the PC monitor is plugged into a power outlet that is
receiving electricity.
2. Have you pressed properly on the On/Off button?
3. Check the picture brightness and contrast settings.
No picture
4. If you connect the PC monitor to a laptop computer, make sure the
laptop has been switched to "Display on external monitor".
5. Check that the cable is properly connected and that it is not
damaged.
Blurred or imperfect
Check that the video cable is properly connected.
Unusual or missing If the red, blue, green or any other colour disappears, check that the
colours video cable is properly connected.
1. Check that the power cord is properly connected.
2. Check for possible interference from another electrical device or tool.
Avoid placing speakers, fluorescent lights, fans, etc. near the screen.
Flickering
3. Access the display settings by pressing the Menu button and then
automatically adjust the image according to the analogue settings (VGA).
The liquid crystal screen (LCD) is a high-tech product that contains about
a million transistors offering a high quality image. Occasionally, a few
blue, green, red dots (corresponding to inactive sub-pixels) may appear
on the screen. This does not affect the performance of your product.
Defective pixels
• European Standard EN 9241-307 class II
Standard EN 9241-307 provides a definition of the characteristics relating
to pixel errors. These are listed in four classes and three types of errors.
Each pixel in turn breaks down into three sub-pixels corresponding to the
basic colours (red, green, blue).
21
