Ausschalten: Lassen Sie den An-/Aus-Schalter los.
FRÄSEN
1. Drücken Sie den Ein/Aus-Schalter.
2. Führen Sie die Fräse langsam zum Werkstück und
tauchen Sie in das Material ein.
3. Fräsen Sie die gewünschte Zone mit gleichmäßigem
Vorschub aus.
4. Bestimmen Sie die gewünschte
Fräsgeschwindigkeit mithilfe des Einschaltknopfes.
5. Lassen Sie den Ein/Aus-Schalter los um die
Oberfräse auszuschalten.
6. Wenn Sie fertig sind, lassen Sie die Oberfräse
zurück nach oben gleiten. Warten Sie noch einen
Augenblick, bis der Motor zum Stillstand gekommen
ist, bevor Sie die Maschine hinstellen.
WARTUNG UND REINIGUNG
Verwenden Sie zum Reinigen der Maschine keine
aggressiven Chemikalien. Verwenden Sie nur ein
trockenes Tuch und eine Bürste.
Dieses Produkt entspricht den
Europäischen Richtlinien.
WARNING AND SAFETY NOTICES
BEFORE USING THE TOOL FOR THE FIRST TIME,
REFER TO THE HAMMERSMITH MULTITOOL
SET MAIN MANUAL FOR ALL RELEVANT
WARNINGS AND SAFETY INFORMATION.
ALL HAMMERSMITH MULTITOOL SERIES
OPERATING INSTRUCTIONS SHOULD BE
RETAINED FOR FUTURE REFERENCE AND BE
PASSED ON TO THIRD PARTIES.
• Always remove the battery before replacing the
router or tool attachment.
• The milling bits have sharp edges. Handle with care.
• Never tighten the clamping nut without a milling bit.
Always use the correct collet for the milling insert.
• Even if the relevant safety regulations are observed
and safety devices are used, not all risks can be
eliminated. The following risks remain:
— Danger of contact with uncovered moving parts.
M32721_HammersmithMultitool_Fra saufsatz_Manual_A5_20220629_MM.indd 4
M32721_HammersmithMultitool_Fra saufsatz_Manual_A5_20220629_MM.indd 4
Hergestellt in China
EN
— Kickback from the workpiece or part of the
workpiece.
• Risk of personal injury due to vibrations. Vibrations
from power tools can cause injuries. Stop work
immediately and see a doctor if you experience
numbness, itching, tingling or pain, or if your skin
becomes discoloured. Depending on the use of
the tool, the vibration values may deviate from
the specified values. The following factors can
influence the level of vibration:
— Incorrect/inappropriate use.
— Unsuitable accessories.
— Processing of unsuitable materials.
— Inadequate maintenance.
• Use clamps or another convenient method to
secure and support the workpiece on a stable
surface. Holding the workpiece with your hand or
against your body will make it unstable and can
lead to loss of control.
• Only use rotary cutting tools that have the correct
shank diameter for the collet attached.
USE
The device is suitable for waxing, polishing and grinding
paintwork, plastics, coatings and other smooth surfaces.
Inserting the cutter into the chuck
Make sure that the router is switched off. If you set the
direction of rotation switch to the centre position, the unit is
secured against being switched on.
1. Press the spindle lock button.
2. Now loosen the tensioning nut with the spanner provided.
3. Insert the milling head into the chuck.
4. Press the spindle lock button and hand-tighten the
clamping nut using the spanner. Caution: Never tighten
the clamping nut when there is no tool in the chuck.
5. After installing the router head, allow the router to rev
up to full idle speed and look for any vibrations that may
indicate an imbalance.
SETTING DEPTH STOP/IMMERSION DEPTH
1. Loosen the depth stop adjustment screw.
2. Place the cutter on the workpiece and set the
desired plunge depth.
3. Fix the depth stop by hand-tightening the
adjustment screw again.
4
