Dieses Produkt entspricht den
Europäischen Richtlinien.

WARNING AND SAFETY NOTICES

BEFORE USING THE TOOL FOR THE FIRST TIME,
REFER TO THE HAMMERSMITH MULTITOOL
SET MAIN MANUAL FOR ALL RELEVANT
WARNINGS AND SAFETY INFORMATION.
ALL HAMMERSMITH MULTITOOL SERIES
OPERATING INSTRUCTIONS SHOULD BE
RETAINED FOR FUTURE REFERENCE AND BE
PASSED ON TO THIRD PARTIES.
• Wear hearing protection when using the
percussion drill. Exposure to noise can cause
hearing loss.
• Never work at a higher speed than the
maximum rated speed of the drill bit.
• Always start drilling at a low speed and with
the drill bit in contact with the workpiece.
• Only apply pressure in a direct line with the
bit, and never apply excessive pressure.
• For applications that generate a lot of dust,
such as percussion and diamond core
drilling, ensure that there is sufficient dust
extraction.
USE
Attention: Secure the device against being switched
on accidentally by moving the direction switch into
the middle position. There is a risk of injury if the
device switches on unintentionally.
1. Turn the chuck anti-clockwise until the drill
opening is large enough to insert the tool (drill
bit holder).
2. Insert the tool as far as possible into the chuck.
3. Turn the chuck clockwise to clamp the tool.
4. To remove the tool, turn the chuck anti-
clockwise and pull it out of the drill hole.
M32723_HammersmithMultitool_Schlagbohraufsatz_Manual_A5_20220629_MM.indd 4 M32723_HammersmithMultitool_Schlagbohraufsatz_Manual_A5_20220629_MM.indd 4
Hergestellt in China
EN
SELECTION OF THE DESIRED OPERATING MODE
A. Drilling: If you want to drill, set the selector
to the drill setting. Insert the drill attachment
corresponding with the material into the chuck.
You can use it for drilling into wood, metal,
plastic, cement, ceramics or any other similar or
comparable material.
B. Percussion drilling: If you want to use the
percussion drill, set the selector to the percussion
drill setting. For drilling holes into concrete, brick,
tile or other materials of similar hardness that will
not splinter (DO NOT use for ceramic or natural
stone) or for driving-in special concrete screws.
C. Screwing: If you want to screw, set the selector
to the screw setting. Before choosing the setting,
pay attention to the material that you want to
screw into. Insert the bit extension or the flexible
bit holder into the chuck. You can use it to attach
different screws and parts.
SPEED SETTING
Use the speed switch to adjust the power that the
screwdriver should apply.
1 - Low power
2 - High power
SETTING THE DIRECTION OF ROTATION:
The direction of rotation of the device can be
changed using the rotational direction switch.
1. Wait until the device has come to a standstill.
2. Move the direction switch to the desired position:
– Clockwise direction of rotation:
→ for drilling and screwing in screws.
– Anti-clockwise direction of rotation:
← for removal of screws.
3. When you move the direction switch to the
middle position, the device is secured against
being switched on unintentionally. The direction
of rotation may only be changed when the
machine is at a standstill.
This product complies with the European
directives.
MISES EN GARDE ET CONSIGNES DE SÉCURITÉ
AVANT D'UTILISER L'OUTIL POUR LA
PREMIÈRE FOIS, REPORTEZ-VOUS AU
MANUEL PRINCIPAL DU KIT HAMMERSMITH
4
