English
Description
This docking station by Delock can be connected to a computer with a USB-C™
Alt-Mode or Thunderbolt™ 3 port and provides a variety of interfaces. Two
monitors can be operated simultaneously at the mini DisplayPort and HDMI
outputs, alternatively a single monitor at the VGA output. Three built-in USB
Type-A ports allow the use of peripherals, and connections for a headset and
gigabit network, as well as an SD / micro SD card reader, complete the features.
With a USB-C™ power supply, laptops such as the MacBook or Chromebook can
be charged during operation.
Note
The product is a Multi-Stream Transport (MST) hub and supports the extended
desktop configuration of DisplayPort 1.2. When Mac OS is used, the same
image is displayed on both ports (mirrored), it is not possible to use both ports
independently of each other.
Specification
• Connectors:
front side:
1 x Gigabit LAN 10/100/1000 Mbps RJ45 jack
1 x mini DisplayPort 20 pin female
1 x HDMI-A 19 pin female
1 x VGA 15 pin female
1 x USB Type-C™ female (power supply)
back side:
3 x USB 3.0 Type-A female
1 x Headset 3.5 mm 4 pin jack
1 x SD / SDHC / SDXC / MMC slot
1 x Micro SD / SDHC / SDXC slot
1 x USB Type-C™ male
• HDMI and DisplayPort ports support: extended and mirror, resolution up to
2560 x 1440 @ 60 Hz or 3840 x 2160 @ 30 Hz (depending on the system and
the connected hardware)
• Functions: Mirrored or Extended (Windows only)
• VGA resolution up to 1920 x 1080 @ 60 Hz
• Transmission of audio and video signals
• Output power: max. 10 W total,
1 x USB Type-A female max. 7.5 W,
2 x USB Type-A female max. 5 W (combined)
• Input power: 1 x USB Type-C™ female max. 60 W
-2-
