TRILUX VIACON LED 80 Serie Demontageanleitung Seite 8

EN
Disassemble LED module and
control gear unit
Pos.
70 The control gear unit is com-
pletely removed.
9.
90 Remove the cover. (2x)
10.
100 Loosen the screw. (8x)
11.
110 Remove the cover. (2x)
12.
120 Loosen the screw. (8x)
13.
130 Remove the lens. (8x)
14.
XX Disconnect the cable from the
LED module using an auxiliary
tool.
15.
140 Remove the LED module. (2x)
140 The LED module is completely
removed.
8 | 30
VIACON LED
DMA-10083 | 220120 | © trilux.com
