EN
For your safety
Read all notes and disassembly
steps carefully.
Explanation of the warning levels
Observe and follow the warnings.
Non-observance of the warnings
may lead to injuries or material
damage!
WARNING! Indicates dangers
which can result in serious and/or
fatal injuries.
CAUTION! Indicates dangers which
can result in injuries or health haz-
ards.
NOTICE. Indicates dangers which
can result in material damage or
malfunctions.
TIP. Indicates information contain-
ing advice or a useful note.
Explanation of important symbols
and pictograms
Identifies expert personnel trained
and authorised to perform disas-
sembly.
Safety notes
WARNING! Risk of electric shock!
Never work on the luminaire with
voltage applied.
CAUTION! Risk of injury! Install the
luminaire components using pro-
tective gloves.
NOTICE. Avoidance of damage to
electrical components. Take mea-
sures for ESD protection.
TIP. The instructions show the
steps to be taken exemplarily for
the type of luminaire shown. The
number of components may vary.
Disposal of waste electrical and
electronic equipment
6 | 30
Always collect and dispose of old
electrical and electronic equipment
separately at the end of its service
life. In case of doubt, seek informa-
tion about environmentally-com-
pliant waste disposal from your
local district authority or special
waste disposal companies. Cur-
rent information on the energy effi-
ciency class of the selected product
version can be found in the corre-
sponding data sheet for the lumi-
naire. Instructions for replacing or
removing the light source in accor-
dance with Regulation 2019/2020/
EU can be found at:
www.trilux.com/EcoDesign
Disassemble LED module and
control gear unit
Pos.
1.
10 Loosen the screw.
2.
20 Open the cover.
3.
30 Loosen the screw. (3x)
4.
40 Remove the gear tray.
5.
50 Loosen the screw. (4x)
6.
60 Loosen the screw. (4x)
7.
XX Disconnect the cable from the
control gear unit using an auxil-
iary tool.
8.
70 Remove the control gear unit.
DMA-10083 | 220120 | © trilux.com
VIACON LED
