16.MIC Fader Volume
Adjusts the mic output sound level.
17.Master Level (Master Level Meter)
Displays the output level following master volume adjustment held for 2 seconds.
Display range: -3dB to +3dB.
18. Cross fader control
This slider is used to cross-fade between the channels CH1 and CH2, i.e. one
channel is faded out (becomes quieter) while the other channel is faded in (becomes
louder). When the cross fader is in the middle position, the channels CH1 and CH2 are
E
played at the same volume.
N
G
19. CUE for CH A / CH B
L
Selects which source will be live to that channel for CH A and CH B.
I
S
H
Specifications
Gain (Channel A-B):
Headphone Impedance:
Frequency Response:
Distortion :
S/N Ration:
Channel Separation:
Phono Sensitivity:
Line Sensitivity:
MIC Sensitivity:
Line Output:
REC Output:
Power Supply:
Dimensions:
Weight: 0.7Kg
Suitable operating systems for USB operation:
- Windows 2000 / XP / Vista / Windows 7
- Mac OS X
WEEE declaration
Your product is designed and manufactured with materials and components of high quality, which are recyclable and can be reused. The symbol
means that your product should be disposed of separately from household waste when it reaches its end of life. Please dispose of this equipment
at your local collection point or recycling center. Please help to protect the environment in which we all live.
All specifications and appearances are subject to change without notice. All information was correct at time of printing. Musikhaus Kirstein GmbH
does not guarantee for the accuracy or completeness of any description, photograph or statement contained in this manual. Printed colors and
specifications may vary slightly from product. Products from Musikhaus Kirstein GmbH are only sold through authorized dealer. Distributors and
dealers are not agents of Musikhaus Kirstein GmbH and have no authority to bind Musikhaus Kirstein GmbH legally in any way. This manual is
protected by copyright. Any copying or reprint, even in excerpts, is only allowed with written consent of Musikhaus Kirstein GmbH. The same
applies to reproduction or copying of images, even in altered form.
0 to -20 dB
32 Ohm
20Hz-20kHz
> 0.1 %
> 80 dB
55dB(1kHz)
20mV, 47kOhm
1V/10kOhm
20mV 600 Ohm
2.0V, 600 Ohm
2.0V, 600 Ohm
DC -5V 500 mA, USB supply
150(W) x 140(D) x 70(H) mm
11
Pronomic DX-40 USB DJ-Mixer
Bedienungsanleitung / Users manual
00029116
Version 06/2012
