Storage

Wine Storage
WINE RACKS
The full-extension wine racks provide easy access to
750 ml bottles, half-bottles, and magnums. When storing
magnums, the rack above must be removed.
To remove a wine rack, pull out to full extension, tilt up,
then lift up and out. Refer to the illustration below. The top
two racks in each compartment cannot be placed in any
other position. These racks can be identified by the small
square cutout located in the right rear corner. Refer to the
illustration below.
The natural cherrywood facing on wine racks can be
stained or replaced with wood to complement cabinetry.
CAUTION
Remove all bottles from the wine rack before
removal.
CUTOUT
Wine rack removal Rack position indicator
DISPLAY RACK
The adjustable display rack is designed for wine to stay in
contact with the cork at any position. Refer to the illustra-
tion below.
To remove the display rack, pull out to full extension, tilt
up, then lift up and out.
CAUTION
Remove all bottles from the display rack before
removal.
Display rack
Storage Drawers
DRAWER DIVIDERS (TALL MODEL)
To reposition a drawer divider:
To move a short divider, slide the divider forward or
1
backward. Refer to the illustration below.
2 One long divider in the top drawer is adjustable. To
remove a long divider, pull the long divider up until it
stops, rotate counterclockwise, then pull upward.
3 To install a long divider, align the grooves with the
drawer tabs, rotate clockwise, then slide down.
SHORT DIVIDER
Drawer dividers
DRAWER REMOVAL (TALL MODEL)
To remove/install a storage drawer:
To remove, pull the drawer open until it stops. Raise the
1
front of the drawer slightly and pull straight out. Refer
to the illustration below.
2 To install, raise the front of drawer and place onto the
slides. Align the back of the drawer with hooks on the
slide, then align the white pegs at the front of the slide
with holes at the front of the drawer.
Drawer removal
subzero.com | 7
