HYTE Revolt 3 Handbuch Seite 2

HYTE Revolt 3 Small Form Factor ITX Case
Contents
• Revolt 3 Case
• Instructions
• PC Headset Adapter
• Accessory Box
(A) 4x Motherboard Screws (M3)
(B) 4x HDD Screws (6-32)
(C) 4x PSU Screws (6-32)
(D) 8x SSD Screws (M3)
Zip Ties
Specs & Compatibility
Material
Color
Dimensions
Motherboard Size
Radiator Support
Clearance
Expansion Slots
Internal 3.5 Bays
Internal 2.5 Bays
Front Interfaces
Dust Filters
Aluminum, Steel, ABS
Black, White
253 x 178 x 409mm (9.9" D x 7" W x 16.1" H)
ITX
120, 240, 140, 280mm up to 35mm thick
Graphics Card: Most cards up to 335 x 140 x 58mm*
Power Supply: SFX, SFX-L (700w 80 Plus Gold SFX-L Optional)
CPU Cooler Height: Up to 140mm
Handle Weight Limit: 30lbs. (14kg)
* See list of compatible graphics cards on HYTE.com
3
1
2
USB 3.2 Gen 2 Type-C x1, USB 3.2 Gen 1 Type-A x2,
Audio/Mic Combo x1
Front (metal mesh), Top, Sides, Rear (magnetic)
A B C
x4 x4 x4
D
x8
