Configure a display device
Please setup your display settings accordingly to your operating system and requirements.
For detailed information, see the corresponding operation manual and description of your
operating system.
Supported video resolutions
The DockingStation supports:
•
Ultra HD resolution via HDMI
•
Full HD resolution via VGA if the connected VGA display supports it.
Number of displays
1
1
2 (Only Mirrored)
Usage of memory card slots
SD card
Insert the SD card into the SD card slot with the bevelled corner in front of it. The golden
PIN's of the card must be directed downwards (blue LED at the top).
microSD card
Insert the microSD card into the microSD card slot with the bevelled corner in front of it. The
golden PIN's of the card must be directed upwards (blue LED at the top).
Single-LUN - the card reader can only work with one memory card at a time
Note: In order to power and charge your connected laptop, its USB Type-C
support USB Power Delivery or Thunderbolt
Important
1.
When connecting the USB Type-C
book
, the mouse to be connected to the USB 3.0 Type-A port will not work
™
immediately; it will have seconds' delay. This problem also occurs with other similar
Type-C
®
adapters (including Apple original 3 in 1 adapter) when connected with
Chromebook
Attention! When plugging in and out a Power Delivery adapter to the Type-C
2.
interface of the IB-DK4027-CPD, the connected USB devices will get disconnected
flashily and then reconnect within a few seconds. In order to prevent possible data
loss or corruption, avoid disconnecting the Power Delivery adapter from AC power
while transferring data.
Manual IB-DK4027-CPD
if the connected HDMI
®
Video output configuration
HDMI
®
VGA
HDMI
+ VGA
®
™
.
™
3.
plug of the IB-DK4027-CPD to a Chrome-
®
display supports it.
®
Maximum resolution/monitor
3820x2160@30 Hz
1920x1080@60 Hz
max 2x 1920x1080@60 Hz
®
port must
®
