- Seite 1 FleXbus Advanced EN Installation Guide IT Guida di installazione FR Manuel d’installation ES Guía de instalación DE Installationsanleitung...
- Seite 2 Connect FleXbus conductor with avec les Serre-Barres et plaques de HCBC clamp and plate maintien HCBC Optional IP2x Boots Cache de protection IP2x optionnel Optional Optional IP55 Conductor Entry Passe conducteur IP55 optionnel Optional Fire Barrier Système coupe-feu optionnel nVent.com/ERIFLEX...
- Seite 3 Cubierta de protección Optionale IP2x-Schutzabdeckung Pg. 11 IP2x opzionale IP2x opcional Optional IP55 Entrada del conductor Pressacavo IP55 opzionale Pg. 12 Eingangsverbindung IP55 opcional Sistema di barriera Optionales Brandschutz System Barrera contra el fuego opcional Pg. 13 antincendio ignifuga nVent.com/ERIFLEX...
- Seite 4 (cesta de cables/perforada/escalera de cables). Utilice las múltiples configuraciones de montaje posibles para adaptarse a su instalación (plano/en el borde...) Cutter Cutter Cutter ≥ 10 mm ≥ 30 mm TQ = 6 Nm nVent.com/ERIFLEX...
- Seite 5 Cutter TQ = 6 Nm 25 mm Cutter Cutter x2 Min Cutter Cutter Cutter CABSBRKTE TQ = 6 Nm 24 mm TQ = 6 Nm nVent.com/ERIFLEX...
- Seite 6 Esta conexión se puede realizar directamente al embarrado o en el disyuntor con los extensores de palma opcionales Design Center Cutter Cutter Type 2 Type 1 Type 2 Pre drilled Plain Plain Flat Flat Bended Design Center nVent.com/ERIFLEX...
- Seite 7 Instale los conductores en los soportes y monte la parte superior de los soportes. Deje los conductores con una longitud extra en la parte superior del transformador/ alimentación. Cutter TQ = 6 Nm nVent.com/ERIFLEX...
- Seite 8 On Edge Support Kit Configuration 1 Conductor per Phase 2 Conductors per Phase 3P+N Flat Support Kit Configuration 1 Conductor per Phase 2 Conductors per Phase 3P+N nVent.com/ERIFLEX...
- Seite 9 FleXbus Exclamation Drill Diameter HCBC HCBC+PE 400-1250 ≥65 mm ≥100 mm >1600 ≥130 mm ≥165 mm Time Management Time Management 220 – 640 mm² 960 – 1810 mm² Time Management Time Management Drill Diameter Time Management Drill Diameter nVent.com/ERIFLEX...
- Seite 10 FleXbus-Leitung mit HCBC-Klemme und Platte verbinden Collegare il conduttore FleXbus con i serrabarre e le piastre HCBC Conecte el conductor FleXbus con la abrazadera HCBC y la placa Exclamation ≤ 14 mm 50 mm 240 mm Cutter Exclamation FLEXPLATE50PE FLEXPLATE100PE Exclamation nVent.com/ERIFLEX...
- Seite 11 Coperchio di protezione IP2x opzionale Cubierta de protección IP2x opcional 508160 508161 FLEXCOND220 FLEXCOND960 FLEXCOND1280 Time Management FLEXCOND360 FLEXCOND1810 508160 508161 FLEXCOND545 FLEXCOND640 FLEXCOND960 FLEXCOND1280 Time Management FLEXCOND1810 Time Management Design Center Design Center ≥ A Time Management Time Management Design Center nVent.com/ERIFLEX...
- Seite 12 A [mm] B [mm] B [mm] 508140 126 508140 8 508141 176 508141 10 508142 126 508142 10 508143 176 508143 12 Time Management Cutter Cutter Ref. 3 - 4 Tq = 2.5 N.m Time Management Time Management Time Management Design Center Design Center nVent.com/ERIFLEX...
- Seite 13 H ≤ 500 mm 508151 Time Management 508155 508150 Time Management Design Center Design Center Design Center Design Center Time Management 508154 508153 2 min Time Management Time Management Time Management Exclamation 508152 Time Management IF ≤ 200 mm ≥ 150mm nVent.com/ERIFLEX...
- Seite 14 nVent.com/ERIFLEX...
- Seite 15 nVent.com/ERIFLEX...
- Seite 16 CADDY ERICO HOFFMAN RAYCHEM SCHROFF TRACER nVent.com/ERIFLEX ©2021 nVent. All nVent marks and logos are owned or licensed by nVent Services GmbH or its affiliates. All other trademarks are the property of their respective owners. nVent reserves the right to change specifications without notice.
