T E C H N I CA L FA CT S
TECH SPECS KONE PRO
ROCCAT
®
Owl-Eye 19K dpi optical sensor
(based on PixArt PAW3370)
400 IPS (10.2m/s) maximum speed
50g maximum acceleration
(stop to maximum speed in 0.03s required to reach limit)
Default DPI steps: 400, 800 (default), 1200, 1600, 3200
1.8m Phantom Flex™ cable length
1000Hz polling rate
Lift-off distance: 1mm, 2mm and surface calibration
ARM32 M0+ MCU
On-board memory
ROCCAT
®
Titan Switch Optical, 100 million click life-cycle
66g weight
Should you need assistance ...
Our support team is ready to help you with any technical questions.
Just send an e-mail to support@roccat.com or visit our website at:
W W W.ROCCAT.COM/SUPPORT
SYSTEM REQUIREMENTS
Windows
®
7, 8 and 10 (software support)
USB 2.0 (or higher)
Internet connection (for driver software)
D R I V E R L E S S S E T U P
Press the profile button in combination with the left mouse button for
three seconds to enter config mode. The mouse will blink in the color
of the active profile. To exit config mode, press the profile button in
combination with the left mouse button for three seconds once more.
Scroll up/scroll down: Change DPI level from 5 available
presets. LEDs will fade into one of the colors listed
below to reflect the chosen DPI preset.
400 DPI – red
800 DPI – green
1200 DPI – cyan
1600 – blue
3200 – pink
Forward side button/backward side button: Change
polling rate. The right mouse button will blink in one of
the colors listed below to reflect the chosen polling rate.
125Hz – blue
250Hz – green
500Hz – yellow
1000Hz – white (default)
Wheel click: Swap between 1mm and 2mm lift-off dis-
tance. The left mouse button will blink in one of the co-
lors listed below to reflect the chosen lift-off distance.
1mm – red
2mm – green
While holding the left mouse button, press forward side
button/backward side button: Change LED brightness
in steps of 10%.
While holding the right mouse button, press forward
side button/backward side button: Change between
Static, Wave, Heartbeat, Breathing or Blinking RGB
modes. The effect is immediately shown on the mouse.
While holding the left or right mouse buttons and wheel
up/down: Change the color of the LEDs corresponding
to the button held from 16 presets. When both are held
at the same time it changes both at once. Changes are
immediately shown on the mouse.
