NB! It is forbidden to use a non-heat-resistant cable with PVC isolation
as the power cable. The joint box must be waterproof and it must be
located up to 50 cm from the floor.
CLIFF
Mini 4
• Open the cover of the heater's electrical box.
• Attach the power cable on the terminal block according to the
circuit diagram.
• Close the cover.
• Fix the cable on the output with a cable strap.
Fittingthestones
Upon stacking the stones, one should monitor that the heating
elements are not bent and that there is a sufficient air circulation
around the heater elements.
• The stones must be washed clean before laying.
• When the stones have been stacked too close to each other, the
heating elements may overheat (= shorter useful life) and slow the
heating of the sauna.
• Stones with a diameter of 3–6 cm are suitable for the heater.
• The stones on the external surface of the heater must fully cover
the heating elements. The heating elements must not be visible.
• Using ceramic stones in the CLIFF heater is allowed upon the
user's responsibility.
ATTENTION! Too sparsely filled stone container causes fire hazard!
6
L1 N
230V 1N
CLIFF 6
CLIFF 9
L1
CLIFF 11
400V 3N
230V 1N
L2 L3 N
