Installation - Maxima 09378030 Handbuch

INSTALLATION

1 The appliance must be positioned on a flat, stable, heat resistant and non-flammable surface.
2
When positioning the appliance, maintain at least 1 meter (3 foot) distance from walls or other objects
for safety and ease of use.
3
Position the appliance in such a way that smoke and heat can easily and safely dissipate.
4 During assembly only loosely tighten the bolts at first, then fully tighten when assembly is complete.
Do not over tighten the bolts, this may cause damage to the appliance or bolts.
5 Install the required parts & accessories.
6 Assemble the three legs using the supplied brackets, bolts & nuts (2x).
7
Fix the legs together using the X bracket and more bolts & nuts (4x) to create the chassis.
8 Mount the brace ring to the chassis.
9 Attach the handles to the brace ring.
10
Place the oven on-top of the chassis.
6
8
7
9
10
6
