1. Use your finger to unlock the lock lever (fig ).
2. Rotate the mounting bracket to 90 degrees (fig ).
3. Remove the mounting bracket from the unit (fig ).
4. Rotate the battery cover using a coin (fig ).
5. Insert a CR2032 battery into the battery compartment with the
polarity + on top. (fig ).
6. Close the battery cover using a coin. (fig ).
7. Replace the mounting bracket to 90 degrees. (fig ).
8. Rotate the mounting bracket until the part locks.
Note: Low Battery Signal
When the AC101 is running low on battery, it will send a signal to
TM TM
the AMPLICALL 100 or AMPLICALL 150 which will make the
corresponding zone icon light up. To replace the battery, you will
need to follow the 8 steps procedure described above.
4
