PRO TOTAL INOX/PRO DELUXE
ZODIAC
CARATTERISTICHE TECNICHE
- Frame in AISI 410 stainless steel/Matte varnish
- Cup tray
- Chrome support plate
- Chrome lever
- ABS tray
- Black ABS or metal grille
- 15-bar pump
- Timed dispenser (long/short coffee)
- Aluminium exchanger
- Solenoid valve
- Brass cartridge and adjustable pod press
- Resistance: 500 w
- Fixed temperature regulator 95°/145° RM
- Tank capacity PET 1.3 L
- Power supply 220v – 50 Hz
- Power supply 110 v – U.S. kit
DIMENSIONI
Width 21 cm | Depth 32 cm
Height 35 cm | Weight approx. 7 kg
FIRST-TIME INSTALLATION
Remove the packaging and make sure that the ap-
pliance is intact. If not, contact your retailer without
using it. All the packaging elements represent SOURC-
ES OF DANGER for children and the handicapped. The
electrical system must be grounded. OFI S.r.l. cannot
be held responsible for damage caused by not ground-
ing the electrical system. Check that the technical
data for the appliance is compatible with that of the
electrical distribution network and your system. Do
not use unapproved extension cables or adapters.
24
7
T1
2
T3
6
(T1 o T3) ON/OFF switch (2) Temperature
indicator light (3) Coffee dispensing switch
(4) Pod compartment closing lever (5) Pod
compartment filter (6) Drip tray (7) 1.3 L tank
compartment lid (8) Delivery spout
4
5
8
