Connecting the Ethernet cable

1. Thread the Ethernet cable without crystal head through the waterproof joints in sequence as
shown in the following figure.
A
2. Fix a crystal head on the Ethernet cable and bind waterproof materials between B and C.
A
3. Insert the crystal head into the ETH/PoE port and screw up A, B, C, and D in sequence.
B
C
B
C
D
D
