Intex PureSpa Greystone Deluxe Square Bedienungsanleitung

NOTE: This quick start guide provides important and useful tips before you start
the setup of your spa. However, it does not address all aspects of spa installation
and use, and you are still required to read, understand, and follow the owner's
manual for proper installation, maintenance, and safe use of your spa.
• Power: This product draws a minimum of 13 AMPS. Most household circuits are 13 to 16 AMPS. If the
circuit breaker trips, please check that no other appliances or other large loads are on the same circuit as
the spa. Never use an extension cord. Unfold the line cord prior to use. Never place the plug on combustible
materials.
• Water Heating: This heater when properly set up and running will raise the water temperature by 2ºC per
hour PROVIDED the spa cover is properly in place. Depending on the starting temperature of the Spa water
and external air temperature, it will take some time to heat up. If the starting temperature of your tap water
is 22ºC and you wanted to raise it by 16º C to 38ºC, the heating time would be 16ºC/2ºC per hour = 8 hours.
For subsequent use the heating time can be shortened by maintaining an idle temperature in the spa (see
HEATING AND WATER TEMPERATURE section). Be sure to keep the cover on the Spa when not in use.
• RCD: This product is provided with a RCD located at the end of the power cord. The RCD must be tested
before each use. Do NOT use the Spa if the RCD does not function properly. (See owner's manual for
proper testing of RCD instructions).
• Filter Cartridge: Inspect and clean the filter cartridge(s) from every day to once a week, and change the filter
cartridge as needed. A dirty filter cartridge can restrict the flow of water into the system and cause E90 error
code. Keep the spa water properly sanitized to extend the life of the cartridge. Refer to the owner's manual
for detailed information on spa water chemistry and balance.
UNFOLDING AND INFLATING YOUR SPA:
• When you unfold the inflatable spa tub you may notice the smell of the material that is normal for
a new product out of the box. It is therefore recommended to inflate the product and leave it
outdoors for a day to air and allow the new product smell to dissipate somewhat before filling the
spa with water.
• Spread the ground cloth with the bubbles facing down over the cleared area where you intend to
setup your spa.
• For spa inflation, familiarize yourself with the spring loaded valve on the spa tub and the air passage
selection dial located on the side of the spa control base to assure fast and proper inflation.
Inflation tips:
• Inflate the cover air bladder first before connecting the spa control base to the spa tub.
• Attach one end of the inflation hose to the cover air bladder valve and the other end to the spa control
base air blower outlet.
• Always turn the air passage selection dial to the intended function first, in this case inflate position
" ", then press
• When inflation is completed, always turn the air passage selection dial to "
the button again to turn it off. Disconnect the inflation hose from the spa control base and from the
air bladder valve. Close and recess the air bladder valve.
• Locate the large connection pipe on the spa tub liner and connect it to the spa control base large pipe,
hand-tighten only.
• Turn the air passage selection dial to inflate position "
tub for about 3-5 minutes until it is firm to the touch but not hard.
• When inflation is completed, always turn the air passage selection dial to "
the button again to turn it off.
• Connect the remain pipes between the spa tub and the control base, hand-tighten only.
SAVE THESE INSTRUCTIONS
READ BEFORE YOU START!
button to inflate. See owner's manual inflation section for further details.
(355IO) 7.5" X 10.3" ENGLISH 06/30/2021
" position first, then press
", then press button to inflate the spa
" position first, then press
355
IO
355-*IO-R0-2206
