SPARE PARTS LIST
REF.NR.
DESCRIPTION
001
SWITCH
002
HANDLE
003
LOCKING BOLT
004
COLLET NUT
005
CUTTING DEPTH STOP
006
CLAMPING LEVER
007
ELECTRONIC SPEED CONTROL
008
ROTOR
009
STATOR
010
CARBON BRUSH (SET)
011
DUSTEXTRACTING ADAPTOR
015
GUIDE ROD
016
GUIDE FRAME
-
OPEN ENDED SPANNER
-
OPEN ENDED SPANNER (COLLET NUT)
-
SPRING COLLET 6 mm
46
UK
TOLEDO NR.
302008
ROUTER
302003
THE NUMBERS IN THE FOLLOWING TEXT
302002
CORRESPOND WITH THE PICTURES AT PAGE 2.
312009
302009
TECHNICAL SPECIFICATIONS
302010
302011
Voltage
Frequency
302012
Power input
302013
No load speed
302014
Max. cutter diameter
302015
Plunge
Collet
302005
Weight
302006
L pa (sound pressure)
L wa (sound power)
302016
Vibration value
312011
Fuses 230 V machines
312012
PACKAGE CONTENTS
1 router
1 cutter
1 parallel guide
1 6 mm collet (1/4")
1 8 mm collet
1 open-ended spanners
1 hexagonal key
1 instruction manual
1 safety instructions
1 guarantee card
Check the machine, loose parts and accessories for
transport damage.
PRODUCTINFORMATION
Fig. A.
The router has been designed for professional routing of
wood, wood products and plastics.
1 on/off switch
2 machine clamp screw
3 clamping lever for depth adjustment
4 handle
5.
collet bracket
6 collet nut
7 router base
8 opening for parallel guide
9 locking bolt for parallel guide
10 revolver-depth stop
11 scale cutting depth
12 locking bolt depth stop
13 adjusting wheel electronic speed control
Ferm
Ferm
SAFETY INSTRUCTIONS
English
The following symbols are used in these instructions for
use:
instructions in this manual.
Carefully read this manual before using the machine.
Make sure that you know how the machine functions and
how to operate it. Maintain the machine in accordance
| 230 V
with the instructions to make sure it functions properly.
| 50 Hz
Keep this manual and the enclosed documentation with
| 550 W
the machine.
| min-
1
| 11500–32000
Electrical safety
| 20 mm
Always check that the power supply corresponds to the
| 32 mm
voltage on the rating plate.
| 6 + 8 mm
| 3.25 kg
| 81,3 dB(A)
| 94,3 dB(A)
| < 4.0 m/s
2
| 10 A
Replacing cables or plugs
Immediately throw away old cables or plugs when they
have been replaced by new ones. It is dangerous to insert
the plug of a loose cable in the wall outlet.
Using extension cables
Only use an approved extension cable suitable for the
power input of the machine. The minimum conductor
size is 1.5 mm
the reel completely.
SPECIAL SAFETY INSTRUCTIONS
When using electric machines always observe
the safety regulations applicable in your country
to reduce the risk of fire, electric shock and per-
sonal injury. Read the following safety instructi-
ons and also the enclosed safety instructions.
Keep these instructions in a safe place!
•
•
Denotes risk of personal injury, loss of life or
damage to the tool in case of non-observance of the
Denotes risk of electric shock.
Your machine is double insulated in accor-
dance with EN 50144; therefore no earthwire
is required.
2
. When using a cable reel always unwind
Check workpieces for any protruding nails etc. and
remove these.
Keep your hands away from the surface to be cut.
3
