swissflex uni 14 75RF bridge basic Bedienungsanleitung Seite 16

uni 14_/22_/20_75RF basic «Touch»
Radio remote control
1 Pocket lamp
2 All motors «up»
3 All motors «down»
4 Emergency light on / off
5 Control system back section «up»
6 Control system back section «down»
7 Control system thigh section «up»
8 Control system thigh section «down»
9 Battery compartment
(on the back of the radio remote control)
In the battery compartment: red teach-in
button
10 3 x AAA-Battery (included in the delivery)
Motor control
11 Connection for mains supply unit
12 Teach-in button / emergency lowering
button (on the external radio receiver) /
emergency light
13 Connection for external radio receiver
14 Switching power supply
15 Battery compartment for emergency
lowering (2 x 9V)
16
Operating instructions
