PUIG 5022 Kurzanleitung

MOTOPLASTIC, S.A.
Molí de la sal, 1 - 08403 Granollers (Barcelona) SPAIN
Tel. 34 93 849 06 33 - Fax 34 93 849 09 88
info@puig.tv - info@puigusa.com
www.puig.tv - www.puigusa.com
ID. DESCRIPCIÓN
1 Pantalla Windshield
2 Tuerca M5 DIN982 Inox M5 DIN982 Inox nut
3 Tornillo phillips M5x13 M5x13 phillips screw
4 Tornillo M5x20 DIN912 Inox M5x20 DIN912 Inox screw
5 Semibrida rótula tuerca Semi-clamp ball-joint nut
5 Semibrida rótula tornillo Semi-clamp ball-joint screw
6 Semi-casquillo manillar Ø22mm Medium-spacer Ø22mm
7 Semi-casquillo manillar Ø26mm Medium-spacer Ø26mm
8 Tornillo M8x55 DIN912 Inox M8x55 DIN912 Inox screw
9 Tuerca M8 autoblocante DIN985 M8 DIN985 locknut
10 Guía varilla Rod guide
11 Brida anterior manillar Front clamp handlebar
11 Brida posterior manillar Rear clamp handlebar
12 Varilla Dim. 4x20mm Inox Rod Dim. 4x20mm Inox
13 Conjunto rótula Ball bearing set
13 Varilla con rótula Dim. 9x200mm Rod with ball bearing Dim. 9x200mm
14 Conjunto soporte Support set
15 Tope exterior goma Rubber outer stop
16 Ribete Trim
17 Tapón tornillo M8 DIN912 M8 DIN912 screw cap
Pg. 1/2
DESCRIPTION REF. QTY.
10263H
TUERCA-D982-746
TORNIP510---233
TORNI-AD912-464
BRIROT01-1-PR16
BRIROT02-1-PR16
CAS29-22-0-PR16
CAS29-26-0-PR16
TORNI-D912--631
TUEA-D985.8-M8-
FIXVARLL-0-PR16
BRIDAANT-0-PR16
BRIDAPOS-0-PR16
VARILI4X20--576
CJROTULA-0-P200
VARILF9X200-591
CONJU-S3PCC-003
TOPEE-VPGT--8/4
RIBETEAHP--900H
TAPA--CHC11450E
CARENABRÍS MODELO
WINDSHIELD MODEL
WINDSCHUTZ MODELL
TREND UNIVERSAL
1
4
4
4
2
2
4
4
2
2
2
2
2
2
2
14
2
2
2 1
1
2
(color negro/black colour/Farbe Schwarz)
(color ahumado/smoke colour/Farbe Getönt)
/dark smoke colour/Farbe Stark Getönt)
(color azul/blue colour/Farbe Blau)
4
2
3
5
13
16
Ref.: 5022
(color ahumado oscuro
Conjunto / Assembly
17
8
10
15
11
6-7
12
11
9
