Installation instructions
CAUTION: The camera's base should be attached to a structural
object, such as concrete, hard wood, wall stud or ceiling rafter
that supports the weight of the camera. If necessary use appro-
priate mounting material (e.g. anchors) instead of the material
enclosed with the camera.
1. Drill three holes for mounting on the ceiling or wall.
2. Place the Easy Adaptors at the pre-drilled installation position and fix it by using
mounting screws.
3. Route the power/video cable to the connecting place.
4. Attach the dome base assembly to the Easy Adaptor.
5. Adjust the camera's viewing angle (Pan, Tilt, Rotation) (Then remove the caution
sticker.)
6. Assemble the dome cover to the dome base unit.
OPEN
Open & Adjust Driver
All manuals and user guides at all-guides.com
LOCK
Plastic Anchor (6x30 mm)
Mounting Screw (3.5x25 mm)
EN
7
