6.2

Left

1. Optical In: Connect your
audio source to these
inputs with an optical
(Toslink) digital audio
cable (not supplied).
6.3

Right

1. Optical Out: Connect
your audio amplifier or
powered speakers to
these outputs using an
optical (Toslink) digital
audio cable (not
supplied).
6.4

Back

1. DC 5V: Connect the
power adapter (included)
and plug it into the
mains.
7 Connection
diagram
6
OPTICAL OUT
Blu-ray player
Active Speakers
OPTICAL IN
1
1
DC 5V
1
Active Speakers
