4. Features
• ultra slim fixed bracket (distance to wall only 19mm)
• universal mounting pattern
• for LCD/plasma TV
• easy installation
• according to:
WB021: VESA standard 400x200
WB022: VESA standard 800x400
• comes with all necessary plugs and screws for assembly and mounting
5. Installation
Refer to the illustrations on pages 2 and 3 of this manual.
(1) Use the wall mounting bracket to determine and indicate the position of the mounting holes.
Use 6 screws, 3 on top and 3 at the bottom of the plate. The distance between the holes
must be at least 200mm and the outer holes must fall to the left and right of the middle of
the plate. Make sure to mount the plate horizontal using the built-in spirit level [X].
• When mounting on a brick or concrete wall, drill holes (at least 60mm deep) at the
indicated positions. Insert the included anchors [E] and mount the wall mounting bracket
on the wall using the 6 included screws [D] and washers [H].
• When mounting on a wooden wall or wall support, drill holes size Ø3mm and at least
60mm deep at the indicated positions. Make sure all the holes are drilled in solid wood
and that they are blind holes (2). Mount the wall mounting bracket on the wall using the
6 included screws [D] and washers [H]. Do not use anchors.
(3) Mount the TV mounting bracket on the back of the TV as close as possible to the centre [a]
and aligned with the top of the TV-screen [b].Depending on the TV screen, use the correct
bolts [G], [J],[K], [M] or [N], together with the correct washers [C]. Make sure that the
threaded inserts of the TV are deep enough to tighten the bolts without damaging the TV.
When necessary (e.g. curved TV-back, bolt too long), use the included plastic spacers [I].
(4) Hook the TV with the TV rails [B] over the wall plate [A].
(5) Slide the safety bar [F] into the gap at the bottom of the TV rails [B] and the wall plate [A].
A padlock (not incl.) can be inserted in the foreseen opening in the safety bar [F] to increase
safety and prevent malicious removal of the TV screen.

6. Technical specifications

LCD/plasma size
max. load
TV to wall
Use this device with original accessories only. Velleman nv cannot be held responsible in
the event of damage or injury resulted from (incorrect) use of this device. For more info
concerning this product and the latest version of this user manual, please visit our
website www.velleman.eu. The information in this manual is subject to change without
prior notice.
© COPYRIGHT NOTICE
This manual is copyrighted. The copyright to this manual is owned by Velleman nv. All
worldwide rights reserved. No part of this manual may be copied, reproduced, translated or reduced
to any electronic medium or otherwise without the prior written consent of the copyright holder.
WB021 - WB022
WB021
23"-37" / 58-94cm
WB022
37"-55" / 94-139cm
60kg / 132lbs
±19mm
