- Seite 1 FHD RESOLUTION 1920x1080P@165Hz 2 7 I N C H F H D R E S O L U T I O N U S E R M A N U A L...
- Seite 2 The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries. Los términos HDMI y HDMI High-Definition Multimedia Interface, y el logo de HDMI son Marcas comerciales o marcas registradas de HDMI Licensing Administrator, Inc.
-
Seite 3: Inhaltsverzeichnis
ICARUS RGB FHD RESOLUTION 1920x1080P@165Hz CONTENTS Product Description ..............................14 Product Overview ................................. 15 Stand Installation ................................. 16 Wall Mounting ................................17 Basic Operation ................................18 lndicator Light ................................18 OSD Menu ..................................19 OSD Menu Functions ..............................20 LED Effects and Gameplus ............................22 Technical Specifications of Product ........................23... -
Seite 4: Important Safety Precautions
Important Safety Precautions Please read all the instructions carefully before using this product. BE SURE TO unplug the power cord when cleaning LCD. Never clean it with liquid detergent or spraying detergent, but wipe it with wet soft cloth. If it is still not clean, please use special detergent for LCD. DO NOT use accessories not authorized by the manufacturer, other wise they may incur danger. - Seite 5 Read the safety instructions carefully and thoroughly. All cautions and warnings on the device or user’ s manual should be noted. Refer servicing to qualified personnel only. Keep the User’ s Guide that comes with the package for future reference. To prevent fire or shock hazard, keep this device Lay this device on a reliable flat surface before away from humidity and high temperature.
-
Seite 6: Precauciones De Seguridad Importantes
Precauciones de seguridad importantes Por favor, lea todas las instrucciones cuidadosamente antes de usar este producto. ASEGÚRESE de desenchufar el cable de alimentación cuando limpie la pantalla LCD. Nunca lo limpie con líquido o detergente en aerosol, pero límpialo con un paño suave y húmedo. Si aún no está limpio, por favor, use un detergente especial para el LCD. - Seite 7 Lea las instrucciones de seguridad con cuidado y detenidamente. Se deben tener en cuenta todas las precauciones y advertencias del dispositivo o del manual del usuario. Remita el mantenimiento a personal cualificado únicamente. Guarde el manual del usuario que viene con el paquete para futuras referencias. Para evitar el riesgo de incendio o de descarga eléctrica, mantenga este dispositivo alejado Coloque este dispositivo en una superficie plana...
-
Seite 8: Précautions De Sécurité Importantes
Précautions de sécurité importantes Veuillez lire attentivement toutes les instructions avant d'utiliser ce produit. Veillez à débrancher le cordon d'alimentation lorsque vous nettoyez l'écran LCD. Ne jamais le nettoyer avec du liquide ou du détergent en spray, mais essuyez-le avec un chiffon doux et humide. Si elle n'est pas déjà propre, veuillez utiliser un détergent spécial pour l'écran LCD. - Seite 9 Lisez les instructions de sécurité attentivement et complètement. Toutes les mises en garde et tous les avertissements figurant sur l'appareil ou sur le manuel de l'utilisateur doivent être notés. Confiez l'entretien de l'appareil à du personnel qualifié uniquement. Conservez le guide de l'utilisateur fourni avec l'appareil pour pouvoir vous y référer ultérieurement. Pour éviter tout risque d'incendie ou de choc Posez cet appareil sur une surface plane fiable électrique, gardez cet appareil à...
-
Seite 10: Wichtige Sicherheitsvorkehrungen
Wichtige Sicherheitsvorkehrungen Bitte lesen Sie alle Anweisungen sorgfältig durch, bevor Sie dieses Produkt verwenden. Achten Sie darauf, das Netzkabel beim Reinigen des LCD-Bildschirms aus der Steckdose zu ziehen. Niemals mit Flüssigkeit reinigen oder Reinigungsmittel sprühen, aber mit einem weichen, feuchten Tuch abwischen. Wenn es nicht schon sauber ist, verwenden Sie bitte ein spezielles Reinigungsmittel für das LCD. - Seite 11 Lesen Sie die Sicherheitshinweise sorgfältig und gründlich durch. Alle Vorsichts- und Warnhinweise auf dem Gerät oder im Benutzerhandbuch sollten beachtet werden. Lassen Sie Wartungsarbeiten nur von qualifiziertem Personal durchführen. Bewahren Sie das im Lieferumfang enthaltene Benutzerhandbuch zum späteren Nachschlagen auf. Um die Gefahr eines Brandes oder Stromschlags zu vermeiden, halten Sie dieses Gerät von Legen Sie dieses Gerät vor dem Aufstellen auf...
-
Seite 12: Importanti Precauzioni Di Sicurezza
Importanti precauzioni di sicurezza Si prega di leggere attentamente tutte le istruzioni prima di utilizzare questo prodotto. Assicurarsi di scollegare il cavo di alimentazione quando si pulisce il display LCD. Non pulire mai con liquidi o spruzzare del detersivo, ma strofinare con un panno morbido e umido. Se non è già pulito, si prega di utilizzare un detergente speciale per l'LCD. - Seite 13 Leggere attentamente e con attenzione le istruzioni di sicurezza. Tutte le precauzioni e le avvertenze presenti sul dispositivo o sul manuale d'uso devono essere annotate. Fare riferimento alla manutenzione solo a personale qualificato. Conservare il manuale d'uso fornito con la confezione per riferimento futuro. Per prevenire il rischio di incendio o di scosse Posare questo dispositivo su una superficie elettriche, tenere il dispositivo lontano da umidità...
-
Seite 14: Product Description
ICARUS SERIES IMPORTANT SAFETY PRECAUTIONS Do not place the monitor in rain, humid environment or open the monitor case to avoid any shock, electrical hazards, and/or mechanical hazards. Operation • Keep the monitor out of direct sunlight and away from stoves or any other heat source. •... -
Seite 15: Product Overview
ICARUS SERIES 2. Product Overview 2.1 Monitor Buttons M Menu Button Press to display the OSD menu or enter sub-menus. Down Button Press to move down in the menus. Up Button Press to move up in the menus. Exit Button Press to exit. -
Seite 16: Stand Installation
ICARUS SERIES 3. Stand Installation Keep the foam underneath the monitor before attaching the stand. Open the package and take out the stand stem and the Take out the back cover and use two screws to mount it stand base mount them with a screw. to the stand. -
Seite 17: Wall Mounting
ICARUS SERIES 4. Wall Mounting This monitor only includes screws which may be used when attaching the monitor to a VESA 75*75mm type mount. No VESA mount or mounting accessory is included. Open the package, take out the product with foam still attached, and gently place it on a desktop or table. Remove the extra parts and the foam covering the back of the monitor. -
Seite 18: Basic Operation
ICARUS SERIES 5.Basic Operation 1. Insert one end of the DP cable into your PC's graphics card. A HDMI Connectors HDMI cable may also be used. A HDMI cables is not included. 2. Connect the other end of the cable to the corresponding connector on your monitor. -
Seite 19: Osd Menu
ICARUS SERIES 7. OSD Menu The On-Screen Display (OSD) Menu may be used to adjust your monitor's settings and appears on screen after turning on the monitor and pressing the M ( ) button. When using the monitor for the first time, settings will automatically adjust to optimal settings according to your computer's standard configuration settings. -
Seite 20: Osd Menu Functions
ICARUS SERIES OSD Menu Functions Main Menu Sub-Menu Options Description Brightness 0~100 Adjust display brightness Contrast 0~100 Adjust display contrast Brightness/ Standard, Game, RTS, Set visual mode Contrast FPS, Movie, Text Turn on DCR function Turn off DCR function Adjust horizontal position of the picture of H. - Seite 21 ICARUS SERIES OSD Menu Functions Main Menu Sub-Menu Options Description Reset Reset monitor configurations Reset MPRT On, Off Turn MPRT on/off Projection Lamp On, Off Setting switch projection lamp Signal source DP 1, HDMI1, HDMI2 Display the input signal Volume 0-100 Adjust audio volume Low blue ray...
-
Seite 22: Led Effects And Gameplus
ICARUS SERIES 8. LED Effects and Gameplus Press any one of the buttons (M, , E, ) to activate the navigation window. Press ) to switch Gameplus modes. Depending on your needs in-game, choose the corresponding game icon. These game icons are primarily designed to optimize your aim during shooting games, though they can be used for other scenarios. -
Seite 23: Technical Specifications Of Product
ICARUS SERIES 9. Technical Specifications of Product Model Newskill Icarus 27" FHD 165Hz-VA-IC27F6-V2P Screen Size 27" Aspect Rstio 16:9 Backlight E-LED Brightness 250cd/m² Panel Resolution DP1.2: 1920*1080 @165Hz, HDMI 1.4: 1920*1080@75Hz Refresh Rate 165Hz Response Time 1Ms（MPRT（ Viewing Angle ≥178°(H)°/ ≥178°(V)°... - Seite 26 M O R E I N F O R M A T I O N A T www.newskillgaming.com...
