INTRODUCTION
SELECT YOUR MODE
You can move the mode switch on the side of the device to 3 positions: Router/AP (Access Point)
mode, Repeater mode and Wi-Fi Hotspot mode.

ROUTER MODE

Internet
Create a Wi-Fi Network

ACCESS POINT MODE

Internet
Add Wi-Fi to an existing Wired Network

REPEATER MODE

Internet
Modem
Extend the wireless coverage of another AP or wireless router.
WI-FI HOTSPOT MODE
WISP Outdoor AP
Internet
Share Wi-Fi from an existing wireless Internet source to your local network.
DIR-505
Modem
DIR-505
Modem Router
Router
(Wi-Fi Hotspot)
DIR-505
DIR-505
DIR-505
Computer
Smart Phone
Computer
Smart Phone
Computer
Smart Phone
Computer
Smart Phone
5
