ESA AUTOMATION EW3 Serie Installationsanweisung Seite 8

1
9
USB FRONT
4 pin female connector
E
W
3
2
0
USB TOUCH
4 pin female connector
E
W
3
2
1
E
W
3
2 1
3 4
2 1
3 4
1 USBVCC (OUT)
2 USBD-
3 USBD+
4 Signal GND
1 USBVCC (OUT)
2 USBD-
3 USBD+
4 Signal GND
