Assemble instructions
Step 7:
12
x
Ø 4 x 45
Step 8:
6
x
Ø 4 x 50
10
10
9
2
x
11
Note:
Make sure the temperature sensor is out about
2 cm from the silicone pipe.
(Pipe>3 cm + sensor >2cm = 5cm away from ceiling).
Step 9:
4
x
Ø 4 x 30
wood plug
12
14
13
