COMFORTPOOL SOLAR PANEL CP-80022 Installation / Benutzerhandbuch Seite 19

9. Connect the hose of the filtration system (hose disconnected from step 6) to Port A of the 4-way valve
and connect the inlet pipe of the solar heater to port B of the 4way valve, then connect the outlet pipe of
the solar heater to port C of the 4way valve, all use stainless steel clamps to tighten.
10. Remove the plug from the backflow of the pool, turn on the valve for the filtration system, and make
sure water flow is freely in all the piping.
11. Plug in the power supply, start the pump, the water begins to circulate, and enter the pool and solar
heater, respectively. The water entering the solar heater passes through the outlet pipe of the four-way
valve and returns to the pool.
12. When the air in the solar heater is completely discharged (no more bubbles appear in the outlet of the
four-way valve, it is recommended to leave it for more than 5 minutes), put the solar heater is vertically,
open the aluminum supporting feet to the 2nd slot. Hold the end of the small aluminum tube with your
hand, turn it counterclockwise, then pull the aluminum tube out to the appropriate length, turn
clockwise, lock the aluminum tube, adjust to the appropriate position, and finally tighten the wing nut to
fix the aluminum foot assembly.
Note: To retract the aluminum feet, first loosen the wing nut and do not force the foot back.
Port A – connect to
filtration system
Remove the plug
Port B – connect to inlet
pipe of the solar heater
Port C – connect to
outlet pipi of the solar
heater
Open the valve of the
filtration system
