Installation - COMFORTPOOL SOLAR PANEL CP-80022 Installation / Benutzerhandbuch

Technical specifications
- Capacity panel: ± 5 liter
- Max. working pressure: 2 bar
Connection port size: 1-1/4" and 1-1/2"
-
Adjustable range for aluminum supporting feet: 40 – 60 cm to the ground
-
- Carton size: 795 x 130 x 795 cm

2. Installation

We advise you to wrap Teflon tape on the ends of all threaded headers and pipe adapters.
1. Remove the solar heating panel and its accessories from the box.
2. Install the sealing ferrule on both ends of the inlet and outlet of the solar heater, then connect the two 1-
1/2-inch hoses, put on the stainless-steel clamp, tighten with a screwdriver.
Sealing ferrule
