Product Overview - Conceptronic C54PSERVUM Benutzerhandbuch

ENGLISH
1
Description of the numbers
1. Status LED's
2. USB Connector
3. RJ45 LAN Connector
4. Init. Button
5. Power Connector
6. Wireless antenna connector (Reverse SMA)
Below you will find the Status LED description, described from left to right.
Status LED Description
POWER Show power state
WIRELESS Show wireless activity
ACT
Show network activity
STATUS Show device activity
USB Show USB connection

4. Product overview

Front View
('Power', 'Wireless', 'Act', 'Status', and 'USB')
(Reset the C54PSERVUM to factory default settings)
(12v DC, 1A)
Back View
2 3 4 5 6
Possible status
Off / On
Off / On / Blink
Off / On / Blink
Off / On / Blink
Off / On / Blink
17
