Beamz 3-SOME Light Set Bedienungsanleitung Seite 22

MENU / MENÜ / MENÚ
Mode
Auto
Sound
Speed
Sensitivity
Silent scene
Addr
Slave
Colour
TECHNICAL SPECIFICATION / TECNISCHE SPECIFICATIE / TECHNISCHE DATEN
/ ESPECIFICACIONES TÉCNICAS / SPÉCIFICATIONS TECHNIQUES /
SPECYFIKACJA TECHNICZNA
Rated voltage
Rated power
LED
Fuse
DMX Channels
Function
Dimensions per unit
Weight (per unit)
The specifications are typical. The actual values can slightly change from one unit to the other. Specifications can
be changed without prior notice.
22
Program
Description
Au-1 Auto program 1
Au-2 Auto program 2
Au-3 Auto program 3
So-1 Sound program 1
So-2 Sound program 2
So-3 Sound program 3
SP 1—SP9 Speed value for program adjustable
Se 1—Se9 MIC value adjustable
OFF The fixture is open light on music by Sound program
ON The fixture is closed light on music by Sound program
4CH 4 channels DMX mode
6CH 6 channels DMX mode
Slav Slave
C1 Red
C2 Green
C3 Blue
C4 White
C5 Red + Green
C6 Red + Blue
C7 Red + White
C8 Green + Blue
C9 Green + White
C10 Blue + White
C11 Red + Green + Blue
C12 Red + Green + White
C13 Red + Blue + White
C14 Green + Blue + White
C15 Red + Green + Blue + White
: AC100～240V 50/60Hz
: 25W
: 171 LEDs total (per unit: 12x red, 18x green, 18x blue and 9x white)
: F1A
: 4 / 6 Channels
: DMX, Auto, Sound active and Master-Slave.
: 610 x 220 x 255mm
: 3.5 kg
