EN
What is included in the box

Supply of this TV includes following parts:
• 1x TV
• 1x Remote control
• 2x AAA batteries
• 1x Mini Component adapter
cable

Attaching the Stand


Please follow the instructions on last page of this user manual.
Getting started - initial set up

1. Insert the batteries supplied into the Remote control.
2. Using the RF cable supplied, connect the TV to the TV Aerial wall
socket.
3. For connecting to the Internet with a wired connection, connect a
Cat 5/Ethernet cable (not included) from the TV to your broadband
modem/router.
4. Connect the power cable to the Electrical outlet and switch the TV on
by using the standby button on the TV.
5. You will be now welcomed with the First Time Installation screen. If
it does not appear, press the standby button on the TV set once, this
will prompt the 'pairing menu' to appear. Scroll through and highlight
'Pair your remote' by pressing the CH+/CH- TV button (scroll up/
down function in the menu) then press the TV set's standby button
(OK function in the menu) to confi rm your selection. Please press
and hold the yellow and green buttons for a few seconds on the
remote control, until white LED on TV front blinked fi ve times.
Press [MENU] then 8-8-8-8 and the First Time Installation screen will
appear.
If you wish to make changes to any of the default settings, use the
scroll ▲/▼/◄/► buttons. To exit this menu at anytime, press [EXIT]
button.
6. Please set desired settings in FIRST TIME INSTALLATION screen.
DVB Antenna - You can choose between Terrestrial (DVB-T), Cable
(DVB-C) or Satellite (DVB-S)*.
Language - Set the TV Menu language.
Country - Set the desired country.
Tunning Mode - Choose if you want to tune only Digital (DTV)
Analogue (ATV) or both Digital and Analogue (DTV + ATV)
Operator - Select Cable provider. If your cable operator is not listed
select Others. (Avaliable only if DVB Antenna is set to CABLE)
Environment - Select the location of TV.
For home use, please select Home Mode.
For shop demonstration mode, set Store Mode.
Sorting by LCN - Set LCN to ON if you want to arrange channels by
provider preferences (only applies to DVB-T and DVB-C channels).
7. Press [Auto Tuning] button to start the tuning process.
8. Optional channel presets DVB-C:
Keep all default settings as recommended.
If DVB-C channels are not found, contact your network provider for the
valid "Network ID". Then perform a new search. Press the [MENU], select
"Network ID" and enter the network ID.
9. Optional channel presets DVB-S2*: Select "Satellite" in the "DVB
Antenna" in the menu for the optional channel presets. Here you can
• 1x RF cable
• 1x TV stand installation packet
• 1x User guide
• 1x Mini Composite adapter
cable
choose between the various satellites. Since selection completed, then
the channel list of the exact satellite will be available to be imported
into your TV system.
Confi rm with [OK] button on the remote control, to start scanning.
TIP: If you are missing channels, the reason for this is likely to be signal
strength, you should consider connecting signal booster and re-tuning the TV.
* - Available only for TVs with DVB-S tuner

Remote control


Radio controlled remote control - No more aiming in the TV direction!
Refer to remote control picture on the second page of this user
manual.
1. STANDBY – Switch on TV when in standby or vice versa.
2. MUTE – Mute the sound or vice versa.
3. 0 – 9 – to select a TV channel directly.
4. TV GUIDE – Opens the 7 Day TV Guide (Digital mode).
5. – To return to the previous channel viewed.
6. PICTURE – Scrolls through picture mode options.
VOL ▲/▼ – To increase / decrease the sound level.
7.
CH ▲/▼ – To increase or decrease the channel being watched.
8.
9. SOUND – Scrolls through sound mode options.
10. SOURCE – To display the input/source menu.
11. MENU – To display OSD menu.
12. EXIT – To exit all menus.
13. (▲/▼/◄/►/ OK) – Allows you to navigate the on-screen menus and
adjust the system settings to your preference.
14. BACK – Back to previous menu.
15. FAV – To display favourites menu.
16. INFO – Press once for now/next channel information. Press twice for
programme information about current programme.
17. TEXT – Teletext mode - To enter Teletext
18. SUBTITLE – To switch the dialogue at the bottom of the screen (on/
off ).
19. TV – Switch to digital TV source.
20. YouTube – Displays YouTube application
21. MEDIA – Switch to USB source.
22. NET+ – Displays AQUOS NET+ menu.
23. Rec 1 – PVR Record
24. – To restart the current chapter
25. – To advance forward to the next chapter
26. – To stop the playback
27. Rec List 1 – Opens the list of recordings.
28. – To play in fast rewind mode.
29. – To play in fast forward mode.
30. – To play/pause
31. COLOUR BUTTONS – Additional teletext and OSD functions
1
- available only with PVR function
