3
Montieren Sie die VESA-Arme (A) rückseitig am Bildschirm.
Mount the VESA arms (A) on the back of the screen.
4 4
4
4 4
Schieben Sie den Bildschirm mit den VESA-Armen seitlich auf die Montageplatte auf.
Slide the screen with the VESA arms sideways onto the mounting plate.
HAGOR Products GmbH | Oberbecksener Straße 97 | D-32547 Bad Oeynhausen | Telefon: +49(0)57 31-7 55 07-0 | Mail: hagor@hagor.de
a/b/cx4
a/b/cx4
dx4
dx4
e/fx4
e/fx4
A
A
A
A
