Pro MISSILE EVO Serviceanleitung Seite 2

A Basebar - 1x
B Extension - 2x
C Armrest - 2x
D 1mm spacer - 2x
E Extension adapter - 4x
F 5mm spacer - 6x
G Basebar adapter - 2x
H Basebar bolt - 4x
I Armrest bolt - 2x
J Thread part - 4x
K Stem - 1x (optional)
L Endcap - 1x
Basebar
A
Brake out
Shift out
Shift (extension) in
from extension/spacer
2
SIMS-PRO Missile EVO 2012.indd 2
I
C
D E
A
L
J
K
Brake in
Shift (basebar) in
B
G
H
Stem
K bottom view stem
Brake in
Shift in
(from basebar)
Brake out
Shift out
