CD SECTION
1. Operation performance
Items
Search time
TOC read time
Ability to play with
an eccentric disk
Ability to play with
an interruption
Ability to play with
a black dot
Ability to play with
fingerprints
2. CD Electrical performance
Items
1. Output level
2. Output level difference between
channels
3. Frequency response (using 1KHz
0dB as reference)
4. Separation
5. THD
6. S/N ration
* Addition: Regarding items 4, 5 use 20KHz low-pass filter.
Regarding item 6 use 20KHz low-pass filter and IHF-A curve filter.
Disc
TCD-782 (A-BEX)
TCD-782
TCD-792R (A-BEX)
TCD-725A 800 um
(4 track)
TCD-725A 800 um
(9 track)
TCD-725A 65 um
(13 track)
Condition
1kHz 0dB
1kHz 0dB
Specifications
Approx 6 seconds
Approx 6 seconds
Should be played
Without noise
Should be played
Without noise
Should be played
Without noise
Should be played
Without noise
20Hz
100Hz
10kHz
20kHz
1kHz
1kHz
1kHz
Note
From 1 track to 20 track
From turning on the
power to playing "01"
on LCD
Specifications
1.2V +/-2dB
Less than 2dB
+/- 3dB
+/- 2dB
+/- 2dB
+/- 3dB
More than 60dB
Less than 0.1%
More than 80dB
