Never place the appliance close to sources of heat such as cookers or radiators, and avoid placing it in
direct sunlight. Standard EN378 specifies that the room in which you install your appliance must have a
volume of 1m³ per 8 g of hydrocarbon refrigerant used in the appliances , so as to avoid the formation of
inflammeable gas/air mixtures in the room where the appliance is located in the event of a leak in the
refrigerant circuit. The quantity of the refrigerant used in your appliances is indicated on the nameplate.
VENTILATION
It is important that the appliance be well ventilated and that air can circulate unhindered above, below
and around it. Figure 2 illustrates how the necessary air circulation can be ensured. Keep ventilation
openings, in the appliance enclosure or in the built-in structure, clear of obstruction. There must be at
least 35 mm clearance between the base of the appliance and the floor
.
IMPORTANT! There must be free
access to the ventilation grille fig 3
( . ).

ELECTRICAL CONNECTION

Data regarding voltage and absorbed
power / current are given on the
nameplate which are stated on the
nameplate on the rear of the appliance. Electrical connection
must be made in accordance with the local regulations.
WARNING
Regulations require that this appliance must be earthed.
If the socket and plug are not of the same type, please
have the plug or socket replaced by a qualified electrician
.
Do under no circumstances use extension leads or adaptors.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

OPERATION AND FUNCTION

The appliance is equipped with electronic controls fig 4
( . ).
For operation of the electronic control, reference is made 1
to the separate instruction manual enclosed in the appliance.
4 2
HOW TO SEE THE MIN TEMPERATURE
3
Press and release the n°2 key.
The "Lo" message will be displayed followed by the
minimum temperature recorded. By pressing the n°2 key
again or by waiting 5s the normal display will be restored.
HOW TO SEE THE MAX TEMPERATURE
Press and release the n°1 key. The "Hi" message will be displayed followed by the maximum
temperature recorded. By pressing the n°1 key again or by waiting 5s the normal display will be
restored.
HOW TO SEE THE SET POINT
Push and immediately release the SET key: the display will show the Set point value - Push and
immediately release the SET key or wait for 5 seconds to display the probe value again.
HOW TO CHANGE THE SETPOINT
Push the SET key for more than 2 seconds to change the Set point value - The value of the set point
will be displayed and the "°C" or "°F" LED starts blinking - To change the Set value push the 1 or 2
arrows within 10s - To memorise the new set point value push the SET key again or wait 10s.
Push the DEF(4) key for more than 2 seconds and a manual defrost will start.
