User Manual
Introduction
Thank you for purchasing the 100m Fibre Optic USB 3.2 Type C Extender. This product has been
designed to provide trouble free, reliable operation. It benefits from both a Lindy 2 year warranty and free
lifetime technical support. To ensure correct use, please read this manual carefully and retain it for future
reference.
This Extender allows you to extend the distance between your host computer and a USB 3.2 device by up
to 100m. It consists of a transmitter and a receiver, which are connected by use of LC Multimode Fibre
Optic cable up to 100m length (not included).
Package Contents
1x Transmitter
•
1x Receiver
•
•
1x USB Cable USB Type A / Micro-B, 0.95m
Lindy Manual
•
Specification
•
USB Standard: USB 3.2 / 3.1 Gen 2
Supported Bandwidth: 10Gbps
•
Maximum Distance: 100m (328.08ft)
•
•
Transmission Medium: Multimode 50µm/125µm OM3
Chipset: Silicon Line SL86050
•
•
Connectors:
•
Transmitter Input: USB Type C (Male)
Transmitter Output: Duplex LC (Female)
•
•
Receiver Input: Duplex LC (Female)
Receiver Output: USB Type C (Male)
•
•
Power: USB Micro-B
•
Operating Temperature: 0° - 50°C (32°F - 122°F)
Storage Temperature: -10°C - 70°C (14°F - 158°F)
•
•
Humidity: 10 - 80% RH (non-condensing)
Power Requirements: 5VDC 2A
•
Installation
Connect the transmitter with the USB Type C port of the host device first, then connect it with the receiver
using a multimode fibre optic cable (not included) with LC Duplex. Please follow the arrows on the units
for correct installation of the fibre optic cable, see diagram below). Finally connect the USB device with
the USB Type C port of the receiver. Please follow this order, otherwise the device might not be recognized
correctly.
The Fibre Optic USB 3.2 Type C Extender is supplied with a USB Type A to Micro-B cable which can be
attached to a second USB port or to a USB Power supply (not included) should additional power be
required.
English
