Figure 3. SmartStor 4 Bay Front View
Keyhole
Note: This SmartStor is shown without the front door.
Please note that the keyhole of the upper and lower side, to avoid
the machine damage or can not be used.
Figure 4. SmartStor 4 Bay Rear View
Power
Button
Warning
Disk Drive
Cooling Fan
USB
Connections
eSATA
Connection
RJ45 Network
Connection
Power
Connection
5

Task 1: Package Contents

Disk Drive
Drive Carrier
Disk Status
LED
Disk Activity
LED
System Status LED
Ethernet
Activity LED
One Touch
Backup Button
