Athena Chair
Design by BoConcept
Samlevejledning - Assembly Instructions - Montageanleitung - Instructions d'assemblage - Instrucciones de montaje
406-1360
406-1370
Chair
E:
B:
C:
D:
A:
R: M8
L:
H: M6 x 15
I:
4mm
G:
Ø10
F:
M8x65
T:
Q: Cup Ø60
K: M6x50
J:M6
S: 6mm
(1370)
944061360-19-06-2018/3
1/3
