safety instruction:
the Mdt-umbrella type e is good for windy conditions up to 60
km/h (7 Beaufort), but it may only be set up with bases which are re-
commended by Mdt. in case of upcoming wind, the umbrella must
be closed and fixed with the ribbon immediately. Mdt does not
assume liability for any damages causes by the use of the umbrella
contrary the instruction manual.
installation instruction:
the distance between each umbrella in fully opened condition
should be at least 20 cm. the corresponding distance between the
ground ankers, please find in the overview. in case, after mounting
the safety pin does not fit in the whole, which was designed for it
in the mast, anymore, it can be drilled again by hand. please never
use the umbrellas without the safety pin!
#1 square umbrella
l2
distance groundtube (middle)
size
3x3
4x4
5x5
6x6
ø 4 (8-eck)
ø 5 (8-eck)
ø 6 (8-eck)
All manuals and user guides at all-guides.com
#1 round umbrella (octagonal)
l1
l 1
distance ground tube
300 cm
320 cm
400 cm
420 cm
500 cm
520 cm
600 cm
620 cm
400 cm
420 cm
500 cm
520 cm
600 cm
620 cm
l 2
424 cm
565 cm
707 cm
848 cm
370 cm
462 cm
554 cm
5
5
all data are approximate data without guarantee
typ e / type e
disclaiMer
oF Warranty
wall
90°
45°
l2
ground tube
distance ground tube
444 cm
585 cm
727 cm
868 cm
390 cm
482 cm
574 cm
. .
