Connection
clarios eco
Wire color
red
blue
black
Connection diagram of the clarios eco without dimmer
See respective drawing in the middle of this manual (p. 12).

M12 plug and cabling system

The connection of the clarios eco versions with M12 connector is quite simple. Plug the connector
of the luminary in a free socket of the M12 cabling system. The M12 cabling system is coded in a
way to avoid wrong wiring or failures.
Please plan the components required for the electrical installation (power supplies, distributors,
extensions and plugs for unassigned M12 sockets) according to the sales documentation of the
M12 cabling system before placing an order.
Assignment of the M12 connector system
Pin number Wire color
M12 plug (if plug is pinched off)
1 brown
2 white
3 blue
4 black
5 green/yellow (gray)
If the M12 connector is subsequently removed and the heater is connected with open cable ends,
the blue wire (S-PWM) must be switched via an external dimmer or connected to ground (-).

Operation

LED lights are extremely energy efficient and, under normal operation, have a very long life. To
ensure the maximum life of the LED and to increase the energy efficiency, the following should be
considered:
■ The turning on and off of the luminary should be carried out by the input circuit of the power
supply.
■ The turning off of the luminary via the PWM signal should not occur permanently since in this
case the electronics unit of the luminary continues operating.
■ Even if the luminary is equipped with a thermal fuse that protects the luminary against thermal
damage, a permanent abnormal operation should be avoided.
■ The heat dissipation of the LED must not be hindered. Therefore, do not cover the spot.
Assignment
+ 24 Volts
S-PWM
ground (-)
5-pin plug clarios eco
24 V +
24 V +
S-PWM
Masse
ground
