Resetting the gateway

Reset the gateway before passing it to third parties to remove all
data. To reset the device, insert a pen into the reset hole on the
front of the gateway and hold the button behind for 10 seconds.
When resetting the gateway, an uninterrupted power supply must
be ensured.
22

Waste disposal

The pictogram with the crossed out dustbin points to the
requirement for separate disposal of electrical and electronic
appliances (WEEE). Such equipment may contain dangerous
and hazardous substances. These machines must be returned to a
designated collection point for the recycling of WEEE and must not
be disposed as unsorted municipal waste. In this way, you contrib-
ute to the protection of resources and the environment. Contact
your local authorities for more information. Children must not play
with plastic bags and packaging material, due to possible injury
or danger of suffocation. Store such material safely or dispose of
environmentally friendly

Declaration of Conformity

HORNBACH Baumarkt AG hereby declares that the wireless system
type "SMART HOME by hornbach" complies with Directive 2014/53/
EU. The full text of the EU Declaration of Conformity is available at
the following Internet address:
www.hornbach.com/productcompliance/
Availability
HORNBACH guarantees 98% annual availability of the service out-
side the hours between 22:00 and 05:00.

Technical data

Model SMART HOME by hornbach
Nominal input voltage of power adaptor 100–240 VAC, 50–60 Hz
Nominal voltage of the gateway 12 VDC
Rated Power 18 W
Protection class III /
III
Degree of protection IP 20
Operating conditions Temperature: 0 °C – 40 °C, relative humidity: 10% – 80% (non-condensing)
Storage conditions Temperature: -20 °C – 60 °C, relative humidity: 0% – 90% (non-condensing)
Size (H x W x D) 127 x 196 x 34 mm
Weight 0.382 kg
Ethernet 1 x LAN (10/100/1000 Mbps)
WiFi: IEEE 802.11b/g/n and IEEE 802.11a/n/ac
Wireless
ZigBee, Z-Wave Module, Bluetooth LE
Frequency bands 868.26 - 868.56 MHz, 2,403 - 2,483 MHz, 5,171 - 5,249 MHz
Max. transmitting power 39.26 mW at 5 GHz
Free field range > 100 m
HB_6415060_2018/02_V1.2 Manufactured for
HORNBACH Baumarkt AG
Hornbachstraße 11
76879 Bornheim / Germany 23
