CARD DESCRIPTION - EXAMPLE OF A CONNECTION TO AN EXCHANGE

Out1= no 220V
Note: in the example shown in the figure, the dialer is powered by fixed charges from the exchange, the free exchange of the alarm
relay is connected to input 1, the OPEN-COLLECTOR 1 output is configured as the absence of an electrical netwrok and is connected
to input 2.
SUPPLY + - = power supply 13.8Vcc
L 1-2-3-4-5 = Lines inputs / outputs -- Configured like Inputs, refer to NEGATIVE -- Configured like outputs, they
give a NEGATIVE when they are activated
RES = reset of the calls in progress (OPEN TO RESET) -- Referred to NEGATIVE --
PHONE = emulation of a wired telephone line
