Introduction
Multiplexing up to 40 channels over one ber pair, it increases the bandwidth, capacity and
maximizes the usefulness of ber. A visual con rmation via LEDs shows that each channel and line
are set up correctly.
LINE
TX RX
FMU-AD402160M3
PWR1 PWR2 RUN OSC
Accessories
Power Cord x2
Plastic Rivet x2
MON
C21 C23 C25 C27 C29 C31
TX RX TX RX TX RX TX RX TX RX TX RX
RX TX RX TX RX TX RX TX RX TX RX TX RX TX
1310 C22 C24 C26 C28 C30 C32
FMU-AD402160M3
Grounding Cable x1
Bracket Screw x4
C33 C35 C37 C39 C41 C43 C45 C47
TX RX TX RX TX RX TX RX TX RX TX RX TX RX TX RX
RX TX RX TX RX TX RX TX RX TX RX TX RX TX RX TX
C34 C36 C38 C40 C42 C44 C46 C48
Cable Manager Frame x1
Bracket Nut x4
C49 C51 C53 C55 C57 C59
TX RX TX RX TX RX TX RX TX RX TX RX
RX TX RX TX RX TX RX TX RX TX RX TX
132179
C50 C52 C54 C56 C58 C60
Cable Ring x7
